DMS 2D Slide

DMS 2D Slide

Active landslides

These columns are intended to monitor active landslides or slope areas that can move more than 5 cm/year. DMS® 2D Slide is an entry level product that combines good tensile strength, fair accuracy and low price.

The standard production has the following characteristics:

  • Biaxial inclinometric sensor (I);
  • Piezometric sensor (U);
  • Temperature sensor (T).
Module length 1 m
Maximum column length 30 m
Material stainless steel 304 (rigid part), high resistance reinforced rubber (joint)
I (inclinometric sensor) range ±20°/±45°, repeatability ±0.05°/±0.02°
U (piezometric sensor) range 30/100 psi
T (temperature sensor) Range -10°/+50°C, resolution 0.1°C

Fill the form below to request information about our products.
